ERFURT LED DB

AREAS OF APPLICATION
Polymer luminaire for ceiling and wall mounting with LED lamps, single or twin lamps. Useable in industrial and public applications, such as swimming pools (see options), and areas with special safety requirements. Version suitable for temperatures up to +55 °C.

HOUSING
Weather-proof and UV-resistant luminaire housing made of fibreglass-reinforced polymer, similar to RAL 9010. Useable for indoor and outdoor areas according to protection rating IP 65 (single or twin lamp) resp. optional IP 67 (single lamp). Thermally separated lamp chamber and driver chamber. Short sealing system consisting of age-resistant, form-retaining silicone/ synthetic rubber.

LIGHTING TECHNOLOGY
Reflector tube with sealing system for easy LED replacement (easy eXchange LED). With reflector tubes that can be swivelled independently made of PMMA Transopal^® (impact strengthened) with internal aluminium reflector (MIRO-SILVER^®). Reflector tube can be locked in increments of 10°. L90 B10 > 60,000 h at 25°C.

ELECTRICAL CONSTRUCTION
Luminaire ready for mounting and installation. Integrated DALI driver, capable of emergency lighting, with through-wiring 5 x 2.5 mm² and additional 2 x 1.5 mm² control cable. Optimized with additional inrush current limiter (ESSB II), 4 kV transient filter. Two M20 cable glands on face side.

MOUNTING
Single or row mounting. Ceiling or wall fixing using two stainless steel mounting clamps with variable mounting distance. Quick-mounting pressure cap with LUCON^® luminaire connection system optionally available (see options). Suspension system possible (see accessories).

NOTE
Listed: DB InfraGO Fahrweg - Group 2.
